Full power, no fan: the Class D amplifiers in the new M2
The new M2 is powered by the latest generation of Class D amplifiers. Their high efficiency makes something possible that was long unthinkable for a device of this size: 4 × 125 watts RMS into 4 ohms, with no fan at all. The highly efficient 500-watt power supply can even deliver 600 watts for short peaks when needed.
Power you can hear
The reserves don't just mean volume – above all, they mean dynamics. The sound stays clear and precise even at high levels. The M2 reproduces fast transients and big dynamic swings cleanly, whether it's rock or classical. This lets it drive even demanding speakers to party volume with ease.
Stress test: one hour at full load without a fan
We pushed the M2 to its limits: all four channels at full power into 4 ohms, with rock music from web radio as the source. Instead of speakers, we connected large load resistors – with real speakers, this test would simply have been unbearable at that level. The room temperature was 24 °C.
The result: For a full hour, the M2 delivered its maximum output, cooled only by its large passive heat sink. Only then did the overheating protection kick in and shut down the power supply. In this case, the M2 simply needs to be restarted once.
To put this into perspective: In everyday use – even at a loud party – the M2 only draws a fraction of this continuous power. For virtually every installation, passive cooling is therefore more than sufficient.
For special cases: the M2 with a fan
Things can only get critical if the M2 is installed somewhere the air can't circulate. The heat then builds up and the air around the device gets very warm itself, especially in summer. For installations like these, the M2 is also available with an active fan, so it can deliver its full power continuously even there. The fan speed is adjustable, and if no cooling is needed, the fan switches off completely.
To order the M2 with a fan, just email sales@trivum.com. The option will be available in the online shop soon. We're also happy to retrofit an M2 you've already bought – simply send it to us. Here too, please get in touch by email first.
Conclusion
Powerful, quiet and honestly tested: the M2 has enough reserves for almost any situation, and for the rare exceptions there's the fan version. Enjoy your next party – or simply your next album in full dynamic range!
